Description
T5 630 W FP 4p EF
Manufacturer: ABB
Product ID: 1SDA054771R1
EAN: 8015644559007
Description: FIXED PART WITHDRAWABLE FOR C.BREAKER TMAX FOUR-POLE WITH EXTENDED FRONT TERMINALS T5 630
Product Main Type: Accessories for Tmax T
Product Type: Fixed Part
Version: W
Suitable For: T5
Suitable for Product Class: Moulded Case Circuit Breakers
Device: Fixed Part
Number of Poles: 4P
Rated Operational Voltage: 690 V AC, 750 V DC
Rated Uninterrupted Current (Iu): 630 A
Short-Circuit Performance Level: L
Standards: IEC
Sub-type: T5
Terminal Connection Type: Withdrawable Circuit-Breakers Front Extended
Test Voltage at Industrial Frequency for 1 Minute: not applicable V
Dimensions (Net): Width 21.8 cm, Height 27.3 cm, Depth/Length 5 cm
Net Weight: 3 kg
Package Level 1: 1 piece
Package Dimensions Level 1: Width 28 cm, Height 28 cm, Depth/Length 36.9 cm
Gross Weight (Package Level 1): 3.2 kg
Package Level 1 EAN: 8015644559007
E-Number (Finland): 3655590
Minimum Order Quantity: 1 piece
Customs Tariff Code: 85389099
Object Classification Code: Q
UNSPSC: 39121100
WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
eClass: V11.1 : 27370422
