Description
XT1N 160 TMD 50-500 3p F F
Product ID: 1SDA067413R1
EAN: 8015644013073
Description: C.BREAKER TMAX XT1N 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 50-500 A
Product Net Dimensions (cm), W x H x D: 7.62 x 13 x 7
Product Net Weight (kg): 1.1
Package Level 1 Dimensions (cm), W x H x D: 12.8 x 13.5 x 14.3
Package Level 1 Gross Weight (kg): 1.134
Customs Tariff Code: 85362090
Rated Current: 50 A
Rated Frequency: 50 / 60 Hz
Rated Operational Voltage: 690 V AC, 500 V DC
Rated Insulation Voltage: 800 V
Rated Impulse Withstand Voltage: 8 kV
Rated Instantaneous Short-Circuit Current Setting: 500 A
Electrical Durability: 8000 cycles
Mechanical Durability: 25000 cycles
Number of Poles: 3
Opening Time: CB with SOR 30 ms and CB with UVR 30 ms
Power Loss per Pole: 3.7 W
Rated Uninterrupted Current: 160 A
Setting Range: 35 to 50 A
Short-Circuit Performance Level: N
Standards: IEC60947-2
Terminal Connection Type: Front with Bolt terminal, tightening torque 6 N·m
Release Type: TMD TM
Circuit Breaker Type: Power Distribution
Product Main Type: SACE Tmax XT
Product Type: Automatic Circuit Breaker
