Description
Product: M E1.2/3 220-250 VAC/DC
Product ID: 1SDA073711R1
EAN: 8015644776442
Description: GEARED MOTOR DEVICE 220…2/350V AC-DC E1.2/3
Order Code US and Canada: ZE1M5
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85389099
Dimensions (cm): Width 10, Height 16.2, Depth/Length 9.2
Weight (kg): Net 0.768, Gross 0.808
Package Level 1: box 1 piece, Width 10 cm, Height 16.2 cm, Depth/Length 9.2 cm, Gross Weight 0.808 kg
Product Main Type: Accessories for Emax 2, Accessories for Emax 3
Product Name: Accessory
Product Type: Accessory
Suitable For: E1.2 and E1.3
Suitable for Product Class: SACE Emax 2 and SACE Emax 3
Technical Details: Configuration Type Loose or configurable, Current Type AC/DC, Rated Voltage (Ur) 220…250 V, Standards IEC/UL
Certificates: ATEX No certification needed, UL No certification needed, VDE No certification needed
Declaration of Conformity: EC Declaration of Conformity Emax E1.2
Instructions and Manuals: Motor M and Contact for signalling springs loaded S33 M/2 – E1.2
Classification: ETIM 9 and 10 EC001030 – Motor operator for power circuit-breaker, IDEA Granular Category Code 5219 Switch part or accessory, Object Classification Code Q, UNSPSC 39121601, WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm), eClass V11.1 : 27370412
