Description
EMC 348 RXF by ABB
Product ID: 1SKM348242C0001
EAN: 6221115042127
Description: EMC348RXF Minicenter, MCB board, Flush, cold roled sheet steel 1mm, 3 Row, 48 modules
Catalog Description: MCB boards-Minicenter, 3Row, 48 modules, Rows: 3, 69 cm x 42 cm x 13.2 cm, Grounded (Class I), IP42
Technical Specifications:
Number of Rows: 3
Cover Plate Type: Door
Door Type: Single
Rated Current (In): 125 A
Surface Finishing: Powder coating
Housing Material: Steel
RAL Number: RAL 7035 – Light Grey
Color: Grey
Number of Modules: 48
Degree of Protection: IP42
Protection Class: Grounded (Class I)
Dimensions:
Width in Number of Modular Spacings: 16
Net Width: 42 cm
Net Height: 69 cm
Net Depth / Length: 13.2 cm
Mounting Type: Flush mounting
Compliance and Certifications:
RoHS: Following EU Directive 2011/65/EU and Amendment 2015/863 (Date: 2024-01-29)
REACH: False – does not contain substances above 0.1 mass percentage (Date: 2024-01-29)
WEEE Category: Product Not in WEEE Scope
Declaration of Conformity – CE available
ETIM Classification: EC000058 – Empty cabinet
eClass: V11.0 : 27142408
Weight: 13 kg
