Description
EMC 312 CF-16
Extended Product Type: EMC 312 CF-16
Product ID: 1SKM804242C0111
EAN: 6221115047672
Catalog Description: MCB boards-Minicenter, 4 Way, 160A, 54 cm x 42 cm x 13.2 cm, Grounded (Class I), IP41
Long Description: EMC312CF-16 Minicenter Compact TP+N busbar type, 160A MCB board, Flush, cold roled sheet steel 1 mm, 4 Way
Technical Specifications: Number of Flange Openings: 0, Number of Conduit Inlets: 15, Cover Plate Type: Door, Door Type: Single
Electrical: Rated Current (In): 160 A
Design: Surface Finishing: Powder coating, Housing Material: Steel, RAL Number: RAL 7035 – Light Grey, Color: Grey, Number of Modules: 12
Material Compliance: RoHS Declaration: EU RoHS Declaration of Conformity Minicenter, RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019, RoHS Date: 20240129, REACH Declaration: EU REACH SVHC Declaration Minicenter, REACH Information: False – does not contain substances > 0.1 mass percentage, REACH Date: 20240129, Conflict Minerals Reporting Template: Conflict Minerals Reporting Template, WEEE Category: Product Not in WEEE Scope
Environmental: Degree of Protection: IP41, Protection Class: Grounded (Class I)
Dimensions: Width: 42 cm, Height: 54 cm, Depth/Length: 13.2 cm, Thickness Cabinet Plate: 1 mm, Thickness Door Plate: 1 mm
Ordering: Package Level 1 Units: 1 piece, Package Level 1 Gross Weight: 11.7 kg
Certificates and Declarations: Declaration of Conformity – CE: Declaration of confirmity CE
Installation: Instructions and Manuals: 1SKC802015C0205, Mounting Type: Flush mounting
Popular Downloads: Data Sheet, Technical Information: 1SKC802015C0205
External Classifications and Standards: ETIM 9: EC000058 – Empty cabinet, ETIM 10: EC000058 – Empty cabinet, eClass: V11.0 : 27142408
