Description
EMC 348 CF-16 by ABB
Product ID: 1SKM816242C0111
EAN: 6221115047719
Description: EMC348CF-16 Minicenter Compact TP+N busbar type, 160A MCB board, Flush, cold roled sheet steel 1mm, 16 Way.
Key Features:
MCB boards-Minicenter, 16 Way, 160A, Dimensions (Height x Width x Depth): 87 cm x 42 cm x 13.2 cm, Grounded (Class I), Degree of Protection: IP41.
Technical Details:
Number of Flange Openings: 0, Number of Conduit Inlets: 15, Cover Plate Type: Door, Door Type: Single.
Electrical: Rated Current: 160 A.
Design and Material: Surface Finishing: Powder coating, Housing Material: Steel, RAL Number: RAL 7035 – Light Grey, Color: Grey, Number of Modules: 48, Cabinet Plate Thickness: 1 mm, Door Plate Thickness: 1 mm.
Environmental Compliance: RoHS Declaration: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019, RoHS Date: 20240129. REACH Declaration: Does not contain substances > 0.1 mass percentage, REACH Date: 20240129.
Standards and Certification: Declaration of Conformity CE available.
Installation: Mounting Type: Flush mounting.
