Standard Features:

Incomer 400A 4P 50KA Adjustable
PV 200KW ,5 xINVERTER 40KW
Busbar 20×10
Suitable Enclosure IP55

Components List:

5 X ABB.1SYS274011R0634: MCB 230/400 V-10kA-4p-C-63A
5 X ABB.2CSF204006R3630: RCCB F204 AC-63/0,3 300mA 4P
1 X ABB.1SVR560730R3402: CM-UFD.M33 Grid feeding monitoring relay
4 X ABB.2CDS211001R0104: Miniature Circuit Breaker – 1P – C – 10 A
1 X ABB.1SDA054341R1: T5S 400 PR221DS-LS/I In=400 4p F F
1 X ABB.1SDA054897R1: MOTOR OPERATOR 230VAC T4-T5
1 X ABB.1SDA054891R1: UNDERVOLTAGE RELEASE
WIRED
220…250V AC-DC
T4-T5-T6

———————————————
Approximate Weight: 74.88 KG
Approx Dimensions (WxHxD): 80x80x30 cm
———————————————
Current LME Price: 10100 USD/Ton
1 EURO = 1.07 USD
Last update date: 01/05/2024
———————————————

360 view
Loading model...

$3,219.24

SKU: 22035_MDB_ABB_COMBOX_IN_400A_200KW_PV_40KW_INV_WITH_G99 Category: Tag:
