ATV12HU22M2 – Variable Speed Drive Altivar 12
The ATV12HU22M2 is a variable speed drive from the Altivar 12 range, designed for simple industrial machines and commercial equipment. It delivers a motor power of 2.2 kW and a maximum horsepower rating of 3 hp, operating on a single phase with a rated voltage range of 200 to 240 V AC.
Key Features: Plug and play solution, electrical cabinet friendly design, energy saving allowing up to 30% energy savings, and less downtime.
Electrical Specifications: Supply frequency is 50/60 Hz ±5 %. Nominal output current is 10 A. The drive includes an integrated EMC filter and provides continuous output current up to 10 A at 4 kHz. Speed drive output frequency ranges from 0.5 to 400 Hz with a speed range of 1 to 20.
Control and Communication: Modbus communication protocol is standard. It has discrete inputs: 4, discrete outputs: 2, analogue input: 1, analogue output: 1, and relay output: 1. Physical interface is 2-wire RS 485 with 1 RJ45 connector.
Performance: Advanced PID regulator, sensorless flux vector control, quadratic voltage/frequency ratio, and voltage/frequency ratio (V/f) asynchronous motor control profiles. Transient overtorque capability ranges from 150 to 170 % of nominal motor torque.
Mechanical Dimensions and Weight: Width: 10.5 cm, Height: 14.2 cm, Depth: 15.6 cm. Net weight is approximately 1.4 kg.
Environmental and Installation: IP20 protection degree, operating altitude up to between 1000 m and 2000 m with corresponding derating, vertical mounting position with ±10 degrees tolerance.
Standards and Certifications: Certified by NOM, CSA, C-tick, UL, GOST, RCM, and KC. Compliant with UL 508C, UL 618000-5-1, IEC 61800-5-1, IEC 61800-3 standards. Marked with CE.
Packaging Details: Primary package dimensions are 18 x 18.5 x 18.5 cm, weight 1.767 kg. Secondary packaging for 30 units measures 75 x 60 x 80 cm with a weight of 65.95 kg.
