Description
Product: EasyPact CVS CVS100B Circuit Breaker
Range: EasyPact
Device Type: Circuit breaker for distribution
Poles Description: 3 poles, 3 protected poles
Rated Current: 100 A at 50 °C
Network Type: AC, frequency 50/60 Hz
Breaking Capacity (Icu): 40 kA rms at 220/240 V AC 50/60 Hz according to IEC 60947-2
Rated Service Breaking Capacity (Ics): 15 kA at 440 V AC, 25 kA at 380/415 V AC, 40 kA at 220/240 V AC 50/60 Hz
Trip Unit: TM-D thermal-magnetic, adjustable long time pickup 0.7 to 1 x In, fixed long time delay and short time delay, fixed instantaneous pickup at 800 A
Protection Type: Overload (thermal) and short-circuit (magnetic)
Impulse Withstand Voltage (Uimp): 8 kV according to EN/IEC 60947-2
Control Type: Toggle switch with contact position indicator
Mounting: Fixed, backplate support, front upside and downside connection, connection pitch 3.5 cm
Dimensions: Width 10.5 cm, Depth 8.6 cm, Height 16.1 cm
Net Weight: 1.5 kg
Standards & Certifications: EN 60947-2, IEC 60947-2, IEC, GOST
Electrical Shock Protection Class: Class II
Ambient Temperature: Operation from -25 to 70 °C, storage from -50 to 85 °C
Packaging: Unit type PCE, 1 unit per package, package weight 1.773 kg
Warranty: 18 months
Customs Tariff Code: 85362010
Description: EasyPact CVS100B is a 3 poles 3d fixed circuit breaker with high performance and cost-saving functionality, suitable for small and medium-sized buildings protection applications. It ensures reliability and continuity of service with modular design enhancing shop floor efficiency and faster switchboard delivery.
