Description
Product Name
Eaton Moeller series BZM – Molded case circuit breaker
Description
Eaton Moeller series Circuit breaker BZME1, Three-pole, 32 A, 415 V, Box terminal
General Specifications
SKU: 109743, Model Code: BZME1-A32-BT, EAN: 4015081093298
Dimensions (L x H x W): 13.02 cm x 8.6 cm x 7.5 cm
Weight: 0.83 kg
Compliance: RoHS conform
Delivery Program
Number of poles: Three-pole
Amperage Rating: 32 A
Technical Data – Electrical
Voltage rating: 415 V – 415 V
Instantaneous current setting (Ii): min 320 A, max 480 A
Overload current setting (Ir): min 0 A, max 0 A
Short delay current setting (Isd): min 0 A, max 0 A
Rated short-circuit breaking capacity Ics (IEC/EN 60947) at 400/415 V, 50/60 Hz: 18 kA
Electrical connection type of main circuit: Frame clamp
Technical Data – Mechanical
Type: Circuit breaker
Mounting Method: Built-in device fixed built-in technique DIN rail (top hat rail) mounting optional
Degree of protection: IP20
Number of auxiliary contacts (change-over, normally closed, normally open): 0, 0, 0
Position of connection for main current circuit: Front side
Handle type: Rocker lever
Design Verification as per IEC/EN 61439 – Technical Data
Rated operational current for specified heat dissipation (In): 32 A
Equipment heat dissipation, current-dependent: 7.7 W
Design Verification as per IEC/EN 61439
Meets requirements for corrosion resistance, thermal stability, resistance of insulating materials to normal and abnormal heat/fire, resistance to ultra-violet (UV) radiation, inscriptions, and clearances and creepage distances.
Other tests and responsibilities lie with the panel builder or are not applicable.
Additional Information
Features: Protection unit
Customs Tariff Code
85362030
