Description
Product Name
Eaton Moeller series BZM – Molded case circuit breaker
SKU and Identification
SKU: 109749, Model Code: BZME1-A50-BT, Catalog Number: 109749, EAN: 4015081093359
General Specifications
Product Length/Depth: 13.02 cm, Product Height: 8.6 cm, Product Width: 7.5 cm, Product Weight: 0.83 kg
Compliances: RoHS conform
Delivery Program
Number of poles: Three-pole, Amperage Rating: 50 A
Technical Data – Electrical
Voltage rating: 415 V – 415 V, Instantaneous current setting (Ii) – min: 480 A, Instantaneous current setting (Ii) – max: 720 A, Overload current setting (Ir) – min: 0 A, Overload current setting (Ir) – max: 0 A, Short delay current setting (Isd) – min: 0 A, Short delay current setting (Isd) – max: 0 A, Rated short-circuit breaking capacity Ics (IEC/EN 60947) at 400/415 V, 50/60 Hz: 18 kA, Electrical connection type of main circuit: Frame clamp
Technical Data – Mechanical
Type: Circuit breaker, Mounting Method: DIN rail (top hat rail) mounting optional Built-in device fixed built-in technique, Degree of protection: IP20, Number of auxiliary contacts (change-over contacts): 0, Number of auxiliary contacts (normally closed contacts): 0, Number of auxiliary contacts (normally open contacts): 0, Position of connection for main current circuit: Front side, Handle type: Rocker lever
Design Verification as per IEC/EN 61439 – Technical Data
Rated operational current for specified heat dissipation (In): 50 A, Equipment heat dissipation, current-dependent: 13.3 W
Features
Protection unit
Customs Tariff Code
85362000
