Description
Product Name
Eaton Moeller series BZM – Molded case circuit breaker
Description
Eaton Moeller series Circuit breaker BZME1, Three-pole, 63 A, 415 V, Box terminal
Specifications
Catalog Number: 109752
EAN: 4015081093380
Dimensions (L x H x W): 13.02 cm x 8.6 cm x 7.5 cm
Weight: 0.83 kg
Compliance: RoHS conform
Number of poles: Three-pole
Amperage Rating: 63 A
Voltage Rating: 415 V – 415 V
Instantaneous Current Setting (Ii) min: 480 A
Instantaneous Current Setting (Ii) max: 720 A
Overload Current Setting (Ir) min & max: 0 A
Short Delay Current Setting (Isd) min & max: 0 A
Rated Short-circuit Breaking Capacity Ics: 18 kA
Electrical Connection Type of Main Circuit: Frame clamp
Mechanical Data
Type: Circuit breaker
Mounting Method: Built-in device fixed built-in technique DIN rail (top hat rail) mounting optional
Degree of Protection: IP20
Auxiliary Contacts: 0 change-over, 0 normally closed, 0 normally open
Position of Connection for Main Current Circuit: Front side
Handle Type: Rocker lever
Design Verification (IEC/EN 61439)
Rated Operational Current for Specified Heat Dissipation (In): 63 A
Equipment Heat Dissipation (current-dependent): 19.5 W
Corrosion Resistance, Thermal Stability, Insulation Resistance, UV Resistance, Inscriptions, Clearances/Creepage Distances: Meet product standard requirements
Additional Aspects: Lifting, Mechanical Impact, Protection against Electric Shock, Incorporation of Switching Devices, Internal Circuits & Connections, Power-frequency Electric Strength, Impulse Withstand Voltage, Testing of Insulative Enclosures, Temperature Rise, Short-circuit Rating, Electromagnetic Compatibility are the panel builder’s responsibility or do not apply
Mechanical Function: Device meets requirements if instruction leaflet is observed
Features
Protection unit
Customs Tariff Code
85362010
