Description
Product Name
Eaton Moeller series BZM – Molded case circuit breaker
Description
Eaton Moeller series Circuit breaker BZME1, Three-pole, 40 A, 415 V, Screw connection
General Specifications
Catalog Number: 109719
EAN: 4015081093052
Length/Depth: 13.02 cm
Height: 8.6 cm
Width: 7.5 cm
Weight: 0.83 kg
Compliances: RoHS conform
Model Code: BZME1-A40
Delivery Program
Number of poles: Three-pole
Amperage Rating: 40 A
Technical Data – Electrical
Voltage rating: 415 V – 415 V
Instantaneous current setting (Ii) min: 320 A
Instantaneous current setting (Ii) max: 480 A
Overload current setting (Ir) min: 0 A
Overload current setting (Ir) max: 0 A
Short delay current setting (Isd) min: 0 A
Short delay current setting (Isd) max: 0 A
Rated short-circuit breaking capacity Ics (IEC/EN 60947) at 400/415 V, 50/60 Hz: 18 kA
Electrical connection type of main circuit: Screw connection
Technical Data – Mechanical
Type: Circuit breaker
Mounting Method: DIN rail (top hat rail) mounting optional; Built-in device fixed built-in technique
Degree of protection: IP20
Number of auxiliary contacts (change-over): 0
Number of auxiliary contacts (normally closed): 0
Number of auxiliary contacts (normally open): 0
Position of connection for main current circuit: Front side
Handle type: Rocker lever
Design Verification as per IEC/EN 61439
Rated operational current for specified heat dissipation (In): 40 A
Equipment heat dissipation, current-dependent: 10.6 W
Features
Protection unit
Customs Tariff Code
85362010
