Description
Product Name
Eaton Power Defense undervoltage release
Catalog Number
PDG3XUV240ACV
Model Code
PDG3XUV240ACV
UPC
786679596135
Dimensions
Length/Depth: 6.1976 cm, Height: 3.302 cm, Width: 3.1496 cm
Weight
0.068 kg
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
IEC 60947-2
CSA
UL 489
CCC Marked
Frame
3
General Information
Circuit breaker type: PD3 Global
Frame size: Frame J-K
Series: Power Defense
Technical Data – Electrical
Voltage rating: 208-240V
Technical Data – Mechanical – Terminals
Terminals: Screw terminal
Technical Information
Undervoltage release: 208-240 V, Screw terminal
