Description
Technical characteristics
Connectivity
With bus system KNX radio: No
Voltage
Operating voltage over bus: 21 – 32 V
Output voltage: 24 – 230 V
Auxiliary tension: 110 – 230 V
Power
Power consumption during operation: 1 VA
Power consumption standby: 0.40 W
Electric current
Max. switching current: 0.16 A
Use conditions
Operating temperature: -5 – 45 °C
Connection
Cross-section flexible conductor: 0.5 – 4 mm²
Cross-section rigid conductor: 0.5 – 4 mm²
Dimensions
Number of width units: 4
Texts
Function: Blocking function can be activated per actuator output via manual operation buttons or bus, With valve protection function
Fuse: Short-circuit proof and overload-proof (display using LEDs)
Type of connection: With screw terminals
Environmental value
RoHS conform: Yes
