SWITCH DISCONNECTOR
Code: 590.GE2013
Series: ISOLATORS-TP Series
Description: The ISOLATORS-TP Series SWITCH DISCONNECTOR is designed for general applications, made of durable engineering plastic. It features a grey/black handle.
Technical Data:
Rated current: 20A
Rated voltage: 690V
Poles: 3
Switch size: Y1
Protection degree: IP66/IP69
Impact resistance: IK09
Glow wire: GW 650°C
Thermal current (Ithe): 25A
Current (Ie) in AC21A (415V/500V/690V): 25A
Current (Ie) in AC22A (415V/500V/690V): 20A
Current (Ie) in AC23A (415V/500V/690V): 20A
Current (Ie) in AC3 (415V): 18A
Current (Ie) in AC3 (690V): 12A
Current (Ie) in DC22A (250V): 25A
Current (Ie) in DC22A (600V): 10A
Power AC23A (415V): 9kW
Short-time current: 400A Icw(1s)
Conditional short circuit current: 10kAeff
Associated fuse type gG: 20A
Terminals flexible wires: 1.5-10mm²
Terminals rigid wires: 1.5-16mm²
Construction type: Enclosed
Mounting version: Surface mounting
Material: Engineering plastic
Colour: Grey/Black
Dimensions (LxWxH): 11x15x8.7 cm
Weight: 0.426 Kg
Additional Features: Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position; Equipped with door interlock; Blank side with drilling point marks on top side base; Break-through cable entries on bottom side base; Reversible base.
Customs Tariff Code: 8536508000
