Description
SWITCH DISCONNECTOR 590.GE8005
Series: ISOLATORS-TP Series
Description: The ISOLATORS-TP Series SWITCH DISCONNECTOR is designed for general applications, featuring a durable construction of engineering plastic. It operates with a rated current of 80A and a rated voltage of 690V, configured with 3P+N poles and a Y2 switch size. The device ensures high protection with IP66/IP69 ratings and an impact resistance of IK09. It is suitable for surface mounting and includes a grey/black handle. The disconnector is equipped with a door interlock and a padlockable handle, accommodating up to three padlocks in the OFF position and one in the ON position. Additional features include a reversible base, late break and early make neutral pole, and break-through cable entries on the bottom side base.
Construction type: Enclosed
Mounting version: SURFACE MOUNTING
Material: ENGINEERING PLASTIC
Colour: GREY/BLACK
Rated current: 80A
Poles: 3P+N
Switch size: Y2
Rated voltage: 690V
Dimensions: 16 cm x 22 cm x 11.5 cm
Glow wire: GW 650°C
Protection degree: IP66/IP69
Impact resistance: IK09
Rated insulation voltage (Ui): 690VAC
Rated impulse voltage (Uimp): 4kV
Thermal current (Ithe): 80A
Current (Ie) in AC21A (415V): 80A
Current (Ie) in AC21A (500V): 80A
Current (Ie) in AC21A (690V): 80A
Current (Ie) in AC22A (415V): 80A
Current (Ie) in AC22A (500V): 80A
Current (Ie) in AC22A (690V): 80A
Current (Ie) in AC23A (415V): 67A
Current (Ie) in AC23A (500V): 67A
Current (Ie) in AC23A (690V): 38A
Current (Ie) in AC3 (415V): 55A
Current (Ie) in AC3 (690V): 32A
Current (Ie) in DC22A (250V): 63A
Power AC23A (415V): 37kW
Short-time current: 1.5kA Icw(1s)
Conditional short circuit current: 10kAeff
Associate fuse – type gG: 80A
Terminals – Flexible wires: 10-35 mm²
Terminals – Rigid wires: 10-35 mm²
Catalogue notes: Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position; Equipped with door interlock; With late break and early make neutral pole; Blank side with drilling point marks on top side base; Break-through cable entries on bottom side base; Reversible base
