Description
General Information
Extended Product Type: CA4-31M
Product ID: 1SBN010140R1131
EAN: 3471523130173
Catalog Description: CA4-31M Auxiliary Contact Block
Long Description: CA4-31M is a 4-pole front mounted auxiliary contact block equipped with screw terminals. CA4-..M version offers terminal assortment matching the marking of 3-pole AF(C)09..16(Z)(B)-30-10 contactors. CA4-31M is available with 3 N.O. and 1 N.C. instantaneous contacts for standard industrial environments.
Ordering
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85389099
Dimensions
Product Net Width: 43 mm
Product Net Depth / Length: 39.5 mm
Product Net Height: 43 mm
Product Net Weight: 0.055 kg
Technical
Number of Auxiliary Contacts NO: 3
Number of Auxiliary Contacts NC: 1
Number of Poles: 4P
Standards: IEC/EN 60947-5-1, UL 60335-2-40 LZGH2 A2L, UL 60947-5-1, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 60947-5-1-14
Rated Operational Voltage: Auxiliary Circuit 690 V
Rated Frequency (f): Auxiliary Circuit 50 / 60 Hz
Conventional Free-air Thermal Current (Ith): acc. to IEC 60947-5-1, Θ = 40 °C 16 A
Rated Insulation Voltage (Ui): acc. to IEC 60947-5-1 690 Vnacc. to UL/CSA 600 V
Rated Impulse Withstand Voltage (Uimp): 6 kV
Terminal Type: Screw Terminals
Container Information
Package Level 1 Units: box 1 piece
Package Level 1 Width: 46 mm
Package Level 1 Depth / Length: 46 mm
Package Level 1 Height: 46 mm
Package Level 1 Gross Weight: 0.055 kg
Package Level 1 EAN: 3471523130173
External Classifications and Standards
Object Classification Code: K
ETIM 7: EC000041 – Auxiliary contact block
ETIM 8: EC000041 – Auxiliary contact block
ETIM 9: EC000041 – Auxiliary contact block
eClass: V11.0 : 27371302
UNSPSC: 39121522
IDEA Granular Category Code (IGCC): 4743 >> Auxiliary contact block
E-Number (Finland): 3706516
E-Number (Sweden): 3211424
