Description
CONNECTOR 313.3243 – OPTIMA Series
Short description: 32A 2P+E 6h 200-250V 50Hz 60Hz Screw terminals
The connector of the OPTIMA Series is engineered for a rated voltage of 200-250V and a rated current of 32A. Featuring a 2P+E configuration and a 6h hour position, it operates efficiently at both 50Hz and 60Hz frequencies. With a protection degree of IP44/IP54, it ensures robust performance in various environments. Equipped with screw terminals and straight type outlets, it offers reliable connectivity. For an alternative aesthetic, a version in black is available by appending “.K” to the catalogue number.
Technical Specifications
Manufacturer: Scame Parre S.p.a.
Commercial Series: OPTIMA Series
Category: Industry > Industrial Plugs and Sockets > Connectors > OPTIMA Series
Mounting version: PORTABLE
Rated current: 32A
Poles: 2P+E
Hour position: 6h
Rated voltage: 200-250V
Working frequency: 50Hz, 60Hz
Colour: BLUE
Material: THERMOPLASTIC
Protection degree: Splash proof
Protection degree IP: IP44/IP54
Protection degree IK: IK08
Types of available outlets: STRAIGHT
Terminals: Screw terminals
Contact material: CuZn (brass)
Cable entry: CABLE GLAND
Catalogue notes: Version also available in black; just add “.K” at the end of the catalogue number.
Product Data
EAN/GTIN: 8001636222837
Customs Tariff Code (INTRASTAT): 8536699099
Net weight: 0.259 kg
Minimum quantity: 10
Packaging
Packaging Box: Quantity 10; EAN 8001636672380; Depth 27.5 cm; Width 22 cm; Height 16 cm; Volume 9680 cm3
Packaging Carton: Quantity 40; EAN 8001636672397; Depth 39 cm; Width 39 cm; Height 31 cm; Volume 47151 cm3
Standards and Certifications
EN IEC 60309-1 (2022) – Plugs, fixed or portable socket-outlets and appliance inlets for industrial purposes – Part 1: General requirements
EN IEC 60309-2 (2022) – Plugs, fixed or portable socket-outlets and appliance inlets for industrial purposes – Part 2: Dimensional compatibility requirements for pin and contact-tube accessories
DIRECTIVE LOW VOLTAGE 2014/35/UE – Low Voltage Directive
CMIM (Marquage Maroc); UKCA marking (UK Conformity Assessed); UE Declaration of conformity
Product Datasheet: PDF technical sheet available from the manufacturer.
