Description
Eaton Moeller series NZM Earth leakage relay
SKU: 285557
Model Code: PFR-5
EAN: 4015082855574
Dimensions (Length x Height x Width): 8 cm x 4.5 cm x 9.5 cm
Weight: 0.192 kg
Compliances: IEC RoHS conform
Certifications: IEC 1009 IEC 1008 IEC 755 IEC/EN 60947-2
Features: Sealable, setting buttons, 1 integrated changeover contact (relay contact)
Temperature rise: The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
Short-circuit rating: Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
Electromagnetic compatibility: Is the panel builder’s responsibility. The specifications for the switchgear must be observed.
Mechanical function: The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
Other product standard requirements met for: Corrosion resistance, verification of thermal stability of enclosures, resistance of insulating materials to normal heat, resistance of insulating materials to abnormal heat/fire by internal electrical effects, resistance to ultra-violet (UV) radiation, inscriptions, clearances and creepage distances.
Non-applicable evaluations: Lifting and mechanical impact since the entire switchgear needs to be evaluated. Also degree of protection of assemblies, protection against electric shock, incorporation of switching devices and components.
Responsibilities of panel builder: Internal electrical circuits and connections, connections for external conductors, power-frequency electric strength, impulse withstand voltage, testing of enclosures made of insulating material.
Frame: 4.5 cm NZM1/2/3/4
Mounting Method: Snap fixing, top-hat rail DIN 46277, IEC/EN 60715
Ambient operating temperature range: -10 °C to 50 °C
Electrical parameters: Current rating of relay contact 6 A, device width 8.5 cm, power consumption 3 W, power on-delay time 5000 ms (max and min), rated control supply voltage (Us) AC 50/60 Hz 184 – 276 V, DC 0 V.
Terminal protection: Finger/back-of-hand proof to BGV A2, VDE 106 part 100 using box terminals top and bottom.
Voltage rating of relay contact: 250 V AC / 100 V DC
Delay time options: 0.02, 0.1, 0.3, 0.5, 1, 3, 5 ms with delay adjustable functions.
Terminal capacity (solid/flexible conductor): 0.75 mm² – 1.5 mm² (2x) with ferrules, 0.75 mm² – 2.5 mm² (2x) solid, 0.75 mm² – 1.5 mm² (2x) flexible/with ferrules.
Type: Accessory, Residual current relays, Voltage release
Special features: Adjustable fault current and delay time, fault current early warning by flashing red LED, pulse-current sensitive, integrated auxiliary contact (1 C/O), ring-type transformer must also be ordered, not UL/CSA approved.
Rated fault current: 0.03 – 5 A
Rated operating voltage (Ue) max: 276 V
Sensitivity type: Pulse current sensitive, type A
