Description
Linergy FT, Comb busbar, 63A, 4 tap-offs, 54mm pitch
SKU: GV2G454
TeSys GV busbar set, 3 phases, 63A/690V, for the upstream parallel wiring of groups of motor starters composed of GV2 motor circuit breakers or LS1D32 fuse carriers. For use with screw clamp terminal devices, it is composed of 4 tap-off outlets for the paralleling of 2 devices with a pitch of 54mm. The use of a terminal block GV1G09 or GV2G05 is recommended to supply the busbar sets (to be ordered separately).
Specifications
Range: Linergy
Product name: FT
Device short name: GV2G
Product or Component Type: Comb busbar
Accessory / separate part category: Connection accessory
Poles description: 3P
Range compatibility: TeSys Deca
TeSys GV2
TeSys K
TeSys U
Fixing mode: Terminals
Number of tap-offs: 4
[Ith] conventional free air thermal current: 63 A
Main
Product Certifications: CE
cULus
[Ui] Rated Insulation Voltage: 690 V
Connection pitch: 54 mm
Width: 206 mm
Net Weight: 0.085 kg
Complementary
Category: US1CTR121253
Discount Schedule: CTR1
GTIN: 3389110555875
Returnability: Yes
Country of origin: RO
Ordering and shipping details
Unit Type of Package 1: PCE
Nbr. of units in pkg.: 1
Package 1 Height: 1.900 cm
Package 1 Width: 3.700 cm
Package 1 Length: 21.600 cm
Package weight(Lbs): 88.000 g
Unit Type of Package 2: S01
Number of Units in Package 2: 50
Package 2 Height: 15.000 cm
Package 2 Width: 15.000 cm
Package 2 Length: 40.000 cm
Package 2 Weight: 4.550 kg
Unit Type of Package 3: P06
Number of Units in Package 3: 1600
Package 3 Height: 75.000 cm
Package 3 Width: 60.000 cm
Package 3 Length: 80.000 cm
Package 3 Weight: 156.500 kg
Contractual warranty
Warranty (in months): 18
