SCAME 570.6413 – SINGLE UNSWITCHED SOCKET 13A 70x87mm
Commercial Series: DOMOPLUS Series
Product Type: Domestic socket
Description: SINGLE UNSWITCHED SOCKET
Type: BRITISH BS1363
Mounting Version: FLUSH MOUNTING
Protection Degree: Splash proof
Protection Degree IP: IP66
Protection Degree IK: IK08
Material: THERMOPLASTIC
Halogen Free: HALOGEN FREE
Working Temperature: -25°C/+60°C
Rated Current: 13A
Rated Voltage: 250V
Dimensions: 7×8.7 cm (70×87 mm)
Flange: 70X87MM_DPL
Catalogue Notes
Not suitable for surface mounting boxes DOMO Series. Suitable for OMNIA-DOMINO-ADAPTO-BLOCK-MBOX Series distribution assemblies.
Product Data
EAN/GTIN: 8001636243160
Customs Tariff Code (INTRASTAT): 8536699099
Net Weight: 0.237 kg
Minimum Quantity: 12
Packaging Box
Quantity: 1
EAN: 8001636243160
Depth: 12.3 cm
Width: 12.3 cm
Height: 9.3 cm
Volume: 1406.997 cm³
Packaging Carton
Quantity: 12
EAN: 8001636691060
Depth: 37.5 cm
Width: 27.5 cm
Height: 21 cm
Volume: 21656.25 cm³
Norms
BS 1363-3 (1995): [British Standard] 13 A plugs, socket-outlets and adaptors. Specification for adaptors.
DIRECTIVE RoHS 2011/65/EU: [European Law] Restriction of the use of certain hazardous substances in electrical and electronic equipment.
Certifications
UE: Declaration of conformity
EAC: Eurasian Conformity
Manufacturer: Scame Parre S.p.a, Via Costa Erta 15 – 24020 Parre (BG) – Italy
