Description
OPTIMA-TOP Series Surface Mounting Socket – 518.3257T
The OPTIMA-TOP Series surface mounting socket is designed for demanding industrial environments, featuring a rated voltage of 346-415V and a rated current of 32A. This 3P+N+E socket supports working frequencies of 50Hz and 60Hz, with a 6h hour position. It offers a high protection degree of IP66/IP67/IP69, ensuring excellent resistance to dust and water ingress. The socket is equipped with screw terminals and angled outlets for optimal connectivity. Additionally, it includes a threaded break-through knock out for secure installation. This product is engineered to meet the rigorous requirements of industrial applications.
Commercial Series: OPTIMA-TOP Series
Mounting Version: SURFACE MOUNTING
Rated Current: 32A
Poles: 3P+N+E
Hour Position: 6h
Rated Voltage: 346-415V
Working Frequency: 50Hz, 60Hz
Colour: RED
Material: THERMOPLASTIC
Protection Degree: Watertight (IP66/IP67/IP69)
IK Protection: IK08
Outlet Type: ANGLED
Terminals: Screw terminals
Contact Material: CuZn (brass)
Cable Entry: M32X1,5
Net Weight: 0.503 kg
