General Information
Extended Product Type: VM205/265
Product ID: 1SFN035203R1000
EAN: 7320500494813
Catalog Description: VM205/265 Mechanical Interlock Unit
Long Description: Mechanical interlock for use with contactors AF116…AF205. For interlocking contactors AF190…205 with AF265…AF370
Ordering
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85389099
Dimensions
Product Net Width: 72 mm
Product Net Depth / Length: 42 mm
Product Net Height: 70.6 mm
Product Net Weight: 0.09 kg
Technical
Terminal Type: Screw Terminals
Suitable For: AF190, AF205, AF265, AF305, AF370, AF190B, AF205B, AF265B, AF305B, AF370B
Suitable for Product Class: Block Contactors
Product Name: Mechanical Interlock Unit
Container Information
Package Level 1 Units: bag 1 piece
Package Level 1 Width: 72 mm
Package Level 1 Depth / Length: 70.6 mm
Package Level 1 Height: 42 mm
Package Level 1 Gross Weight: 0.11 kg
Package Level 1 EAN: 7320500494813
External Classifications and Standards
Object Classification Code: R
ETIM 7: EC001044 – Mechanic interlock for switch
ETIM 8: EC001044 – Mechanic interlock for switch
ETIM 9: EC001044 – Mechanic interlock for switch
eClass: V11.0 : 27371303
UNSPSC: 39122221
IDEA Granular Category Code (IGCC): 5219 >> Switch part or accessory
E-Number (Norway): 4117835
E-Number (Sweden): 3210178
