General Information
Extended Product Type: XT2S 160 Ekip C Dip LSIG In10A 4pFF
Product ID: 1SDA067851R1
EAN: 8015644017477
Catalog Description: XT2S 160 Ekip C Dip LSIG In10A 4pFF
Long Description: C.BREAKER TMAX XT2S 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP C DIP LSIG R 10 A
Ordering
EAN: 8015644017477
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85362090
Dimensions
Product Net Width: 120 mm
Product Net Height: 130 mm
Product Net Depth / Length: 82.5 mm
Product Net Weight: 1.6 kg
Container Information
Package Level 1 Units: box 1 piece
Package Level 1 Width: 130 mm
Package Level 1 Height: 208 mm
Package Level 1 Depth / Length: 145 mm
Package Level 1 Gross Weight: 1.6 kg
Package Level 1 EAN: 8015644017477
Additional Information
Circuit Breaker Type to be Associated: Power Distribution
Product Main Type: SACE Tmax XT
Product Name: Moulded Case Circuit Breaker
Product Type: Automatic Circuit Breaker
Version: F
Technical
Current Type: AC
Number of Poles: 4P
Rated Current (In): 10 A
Rated Frequency (f): 50/60 Hz
Rated Impulse Withstand Voltage (Uimp): 8 kV
Rated Insulation Voltage (Ui): 1000 V AC
Rated Operational Voltage: 690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics): (220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 36 kA
(525 V AC) 25 kA
(690 V AC) 12 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu): (220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 36 kA
(525 V AC) 25 kA
(690 V AC) 12 kA
Rated Uninterrupted Current (Iu): 160 A
Release: Ekip C Dip LSIG
Release Type: EL
Short-Circuit Performance Level: S
Standards: IEC60947-2
Sub-type: XT2
Terminal Connection Type: Front
External Classifications and Standards
ETIM 9: EC000228 – Power circuit-breaker for trafo/generator/installation protection
Object Classification Code: Q
UNSPSC: 39120000
WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
eClass: V11.1 : 27370409
