General Information
Extended Product Type: OFAF000H16
Product ID: 1SCA022627R0660
EAN: 6417019205472
Catalog Description: OFAF000H16 HRC FUSE LINK
Long Description: Fuselink, rated current 16A, size NH000, rated voltage 500VAC / 250VDC, utilization category gG, rated breaking capacity 120 kA (AC) / 80 (kA DC)
Ordering
Minimum Order Quantity: 3 piece
Customs Tariff Number: 85361050
Country of Origin: Hungary
Dimensions
Product Net Width: 21 mm
Product Net Height: 79 mm
Product Net Depth / Length: 53 mm
Product Net Weight: 0.12 kg
Container Information
Package Level 1 Units: box 9 piece
Package Level 1 Width: 21 mm
Package Level 1 Depth / Length: 79 mm
Package Level 1 Height: 53 mm
Package Level 1 Gross Weight: 1.134 kg
Package Level 1 EAN: 6417019205472
Technical
Fuse Size: NH000
Fuse System: DIN
Fuse Type: gG
Power Loss: at Rated Current 1.8 W
Rated Current (In): 16 A
Rated Voltage (Ur): 500 V
Standards: IEC 60269
Utilization Category: gL/gG (Cable protection/equipment protection)
External Classifications and Standards
Object Classification Code: F
ETIM 9: EC000055 – Knife blade fuse
ETIM 10: EC000055 – Knife blade fuse
UNSPSC: 39121600
eClass: V11.1 : 27142005
WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland): 3112016
E-Number (Sweden): 2040010
