Description
PLUG 63A 2P+E 6h 200-250V 60Hz 50Hz Mantle terminals
Cod. 213.6333
The plug from the OPTIMA Series is designed for a rated voltage of 200-250V and a current of 63A. Featuring 2P+E poles and a 6h hour position, it operates efficiently at both 50Hz and 60Hz frequencies. With a protection degree of IP44/IP54, it offers reliable performance in various environments. The plug is equipped with mantle terminals and is compatible with straight type outlets. A version in black is also available by appending “.K” to the catalogue number. This product is engineered to meet the demands of professional applications, ensuring dependable functionality and versatility.
Tech Data
Commercial Series: OPTIMA Series
Synthetical description: PLUG
Mounting version: PORTABLE
Rated current: 63A
Poles: 2P+E
Hour position: 6h
Rated voltage: 200-250V
Working frequency: 60Hz, 50Hz
Colour: BLUE
Material: THERMOPLASTIC
Protection degree: Splash proof
Protection degree IP: IP44/IP54
Protection degree IK: IK08
Types of available outlets: STRAIGHT
Terminals: Mantle terminals
Contact material: CuZn (brass)
Surface treatment contacts: Nickel-plated
Cable entry: CABLE GLAND
Catalogue notes: Version also available in black; just add “.K” at the end of the catalogue number.
Product
EAN code: 8001636295923
INTRASTAT code: 8536699099
Net weight: 0.513 KG
Minimum Quantity: 6
Packaging
Packaging Box
Quantity: 6
EAN code: 8001636742953
Depth: 308.0 MM
Width: 268.0 MM
Height: 180.0 MM
Volume: 14857.92 CCM
Packaging Carton
Quantity: 24
EAN code: 8001636742960
Depth: 560.0 MM
Width: 375.0 MM
Height: 345.0 MM
Volume: 72450.0 CCM
