Product Name: EasyPact CVS
Device Short Name: CVS100B
Type: Circuit breaker for distribution
Poles: 3P with 3 protected poles (3D)
Earth Leakage Protection: Without
Rated Current at 50 °C: 50 A
Network Type: AC
Utilisation Category: Category A
Breaking Capacity (Icu): 40 kA at 220/240 V AC 50/60 Hz according to IEC 60947-2
Trip Unit: TM-D, Thermal-magnetic technology, rating 50 A at 50 °C
Protection Type: Short-circuit (magnetic) and overload (thermal)
Rated Impulse Withstand Voltage (Uimp): 8 kV conforming to EN/IEC 60947-2
Network Frequency: 50/60 Hz
Breaking Capacity Code: B
Service Breaking Capacity (Ics): 15 kA at 440 V AC, 25 kA at 380/415 V AC, 40 kA at 220/240 V AC 50/60 Hz according to IEC 60947-2
Mechanical Durability: 30000 cycles
Electrical Durability: 12000 cycles at 415 V In according to IEC 60947-2
Control Type: Toggle
Long Time Pick-up Adjustment (Ir): Adjustable from 0.7 to 1 times In
Long Time Delay Adjustment: Fixed
Short Time Delay Adjustment: Fixed
Instantaneous Pick-up Adjustment (Ii): Fixed, range 500 A
Contact Position Indicator: Yes
Mounting: Backplate fixed, with front upside and downside connections
Connection Pitch: 3.5 cm
Dimensions (W x D x H): 10.5 cm x 8.6 cm x 16.1 cm
Net Weight: 1.5 kg
Standards: IEC 60947-2, EN 60947-2
Certifications: IEC, GOST
Electrical Shock Protection Class: Class II
Ambient Air Temperature for Operation: -25 to 70 °C
Ambient Air Temperature for Storage: -50 to 85 °C
Package: 1 piece, weight 1.773 kg
Warranty: 18 months
Customs Tariff Code: 85362010
